Display and operating unit
The charger is equipped with five light elements (one is a red/white dual LED) and a graphic
al
touch display (optional)
. The LEDs indicate the state of charge and an error code in the event
of an error. The meaning of the LED display is described below.
LED display
operating status
during charging process
LED indication
note
No battery
X (
w
hite)
B
attery connected /
Charging preparation
O (white)
D
eep
-
discharge start
O
M
ain charge
X
B
ackup charge
X
incl. equalizing charge
E
nd of charge/
C
harge retention
X
P
ause mode
O
O
alternate flashing
O
X
optional
F
ast charge
X
X
optional
D
esulfation
O
Electrolyte Circulation (EC) (X) (O) (X) X
charging phase LED
lights up additionally
operating
status
in the event of an error
B
attery error
X (
r
ed)
T
ime
or capacity
error
X
X (r
ed)
System
error
X
X
X (r
ed)
C
ommunication error
X
X (r
ed)
T
emperature
error
X
X
(r
ed)
w
arnings
optional
charging continues
T
emperature sensor of the
battery defect or not connected
(X) (X) (X) O (red)
charging phase LED
lights up additionally
EC pressure loss (X) (X) (X) O
charging phase LED
lights up additionally
X = permanent light, O = flashing light
