13
USB1: External USB 3.2 Gen 2 Connectors
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
VCC
10
VCC
2
USB_DATA0-
11
USB_DATA1-
3
USB_DATA0+
12
USB_ DATA1+
4
GND
13
GND
5
USB3_RX0-
14
USB3_RX1-
6
USB3_RX0+
15
USB3_ RX1+
7
GND
16
GND
8
USB3_TX0-
17
USB3_TX1-
9
USB3_TX0+
18
USB3_TX1+
