IEI Technology WAFER-JL-N5105 Quick Installation Guide

6
DP1
External DisplayPort connector
HDMI1
External HDMI connector
J_CMOS1: Clear CMOS Button
PIN NO.
DESCRIPTION
NC (default)
Keep CMOS Setup
(Normal Operation)
Press button
Clear CMOS Setup
J_ATX_AT1: AT/ATX Power Mode Setting
PIN NO.
DESCRIPTION
Short A - B
ATX Power Mode (default)
Short B - C
AT Power Mode
ME_FLASH1: ME Override Setting Jumper
PIN NO.
DESCRIPTION
Open
Disable (default)
Short
Enable
AUDIO1 : Internal Audio Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
HDA_SYNC_R
2
HDA_BIT_CLK_R
3
HDA_SDOUT_R
4
HDA_PCBEEP_R
5
HDA_SDIN_R
6
HDA_RST#_R
7
P5V
8
GND
9
P12V
10
GND
PWR1: ATX 12V Power Connector
PIN NO.
DESCRIPTION
PIN NO.
DESCRIPTION
1
GND
3
+12V
2
GND
4
+12V
