BL3x-MT-EN-08 page 18/59
Out Of Service Apparatus out of service. This may be caused by the following
events:
1) Time out during opening (see “Open Time Out”
message).
2) Time out during closing (see “Close Time Out” error) +
allotted number of tries to close have been executed
(see "Close Retries" message).
3) Arm is unhinged (see "Arm Swing Off" message).
4) Locking or unlocking failure of the BL4x (see "Unlock
BL4x Er" message).
5) Defect of the frequency inverter.
Time Adjust Modification of the date and time.
Access Level Chg Change to the access level.
OOS Restore Apparatus put back in service (after it has been out of service)
=> see the “RestartMode” parameter under the “OPTIONS”
menu.
Test Intensive Activation of the intensive test.
Lock Open The Lock Open command of the test mode has been activated.
Lock Close The Lock Close command of the test mode has been activated.
Safety Arm Safety arm (only with the “rubber protection profile” option:
Rubber strip that detects when the arm makes contact with a
vehicle).
Sw Manual Crank presence sensor activated (for manual handling of the
obstacle).
Reset Sensor Init Change of the positioning sensor type (cf. "Positioning"
parameter of "QUICKSTART" menu).
LS Fault Both opening and closing limit switches are activated
simultaneously or badly connected during 100 ms, while
"Positioning" parameter of the "QUICKSTART" menu is set to
"Limit Switches".
Reset LS Fault Limit switch problem resolved (see “LS Fault” error).
Analog. Fault The analogue sensor send measure 0 or 1000 during minimum
100 ms. This may result from a defective wiring, a wrong
positioning of the sensor in front of its cam, a defective sensor,
etc.
OP Power Cut Unlocking of the obstacle following an outage of the supply
voltage (if “QUICK START” ► “Power Fail OP” ► “ON”).
OP Power Blip Unlocking of the obstacle following a micro-outage of the supply
voltage (the voltage drops to 0 V during a few milliseconds) (if
“QUICK START” ► “Power Fail OP” ► "ON").
In this state, the obstacle is STOPPED but still operational,
because the supply voltage has returned. The apparatus waits
for the next command to execute a movement.
CoolingMotor ON Start-up of the motor cooling fan.
Note
: This message is only displayed if the “Cooling – Log”
(below) is “ON”.
CoolingMotor OFF Stopping of the fan that cools the motor.
Note
: This message is only displayed if the “Cooling – Log”
(below) is “ON”.
