Min Sensor Max
0000 0000 0000
(default) (default) (default)
to to to
1024 1024 1024
This parameter applies to the analogue sensor (see the
“Positioning” parameter above) and allows viewing the
current value of the sensor (“Sensor”) (reflection of the
angular position of the obstacle) in its measurement range
(“Min" and “Max” being the sensor values at the extreme
positions of the obstacle: completely open and closed).
Menu Access Choice of the display mode for the menus.
Simplified (default) Access to the menus included in the Simplified mode.
Warning
: pressing the OK key to validate the passage from
the Extended to the Simplified mode causes a movement of
the arm (opening or closing), even if a presence is detected
by the Presence sensors.
Extended Access to supplementary parameters.
Table of incompatibility
between the exploitation modes and the presence sensor function:
; compatible
: incompatible
Exploitation mode
2 Contacts 1 Contact Step by Step Dead Man 2 Contacts CFE
Desactivated
; ; ; ; ;
Opening
; ; ; : ;
CL_Stop+CL
; ; ; : ;
CL_OP+CL
; ; ; : ;
Nothin_Stop+CL
; ; ; : ;
Nothing_OP+CL
; ; ; : ;
Nothing_Stop
; ; ; ; ;
Sensor Function
Nothing_OP
; ; ; : ;
