BL3x-MT-EN-08 page 48/59
BL32/BL33 balance table
Arm length (up to) Number and Ø of
springs
Fixing points Distance "x"
Lateral arm BL32
3.00m 1 x Ø 10mm A-3 420 mm
3.50m 1 x Ø 10mm A-3 415 mm
4.00m 2 x Ø 10mm B-5 395 mm
4.50m 2 x Ø 10mm B-5 386 mm
5.00m 2 x Ø 10mm A-3 414 mm
5.50m 2 x Ø 10mm A-2 406 mm
6.00m 3 x Ø 10mm B-5 398 mm
6.50m 3 x Ø 10mm B-5 390 mm
7.00m 3 x Ø 10mm B-3 384 mm
Central arm BL32
3.00m 1 x Ø 10mm A-2 395 mm
3.50m 2 x Ø 10mm B-5 402 mm
4.00m 2 x Ø 10mm B-3 397 mm
4.50m 2 x Ø 10mm B-3 384 mm
5.00m 2 x Ø 10mm A-1 405 mm
5.50m 2 x Ø 10mm A-1 415 mm
6.00m 3 x Ø 10mm B-3 386 mm
6.50m 3 x Ø 10mm A-1 413 mm
7.00m 3 x Ø 10mm A-1 410 mm
7.50m 3 x Ø 10mm A-1 400 mm
8.00m 3 x Ø 11mm A-2 419 mm
8.50m 3 x Ø 11mm A-1 400 mm
9.00m 3 x Ø 11mm A-1 409 mm
Central arm BL32 with electromagnetic tip support
4.50m 3 x Ø 11mm B-5 389mm
BL33 arm
3.00m 3 x Ø 10mm B-3 400 mm
3.50m 3 x Ø 10mm A-1 406 mm
4.00m 3 x Ø 10mm A-1 405 mm
BL33 arm with electromagnetic tip support
3.00m 3 x Ø 10mm B-3 390 mm
3.50m 3 x Ø 10mm A-1 411 mm
4.00m 3 x Ø 10mm A-1 398 mm
Table with most common configurations. Value "x" is spring length with arm in vertical position.
