INSTALLATION
Select a level surface that provide enough open space for the
intake and/or outlet vents.
The minimum installation height is 85cm.
Leave a minimum clearance of 30cm above the oven and
10 cms at the back, a minimum clearance of 20cm is required
between the oven and any adjacent walls.
Do not remove the legs from the bottom of the oven.
Blocking the intake and/ or outlet openings can damage the
oven.
Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your
radio or TV reception.
20cm
30cm
10cm
20cm
min 85cm
Plug your oven into a standard household outlet. Be sure the
voltage and the frequency is the same as the voltage and the
frequency on the rating label.
WARNING: Do not install oven over a range cooktop or other
heat-producing appliance. If installed near or over a heat
source, the oven could be damaged and the warranty would be
void.
The accessible surface may be hot during operation.
