IO-Link Master with Modbus TCP Interface DataLine 4 Ports IP 65 / IP 66 / IP 67
74
>
Note: Exception Codes
54689
If processing the function code request was without error, the response message will have the
following content:
 Response Function Code: Request Function Code
 Response Data: Requested data
If an error occurs while accessing the registers, the AL1340 replies with an error code instead of the
function code. The response message has the following content:
 Response Function Code: Error Code (= Request Function Code + 0x80)
 Response Data: Exception Code
The following exception codes are available:
Exception Code
Name
Description
0x1
ILLEGAL FUNCTION
Invalid function code
0x2
ILLEGAL DATA ADDRESS
Invalid data address
0x3
ILLEGAL DATA VALUE
Invalid data values
0x4
SERVER DEVICE FAILURE
Error in IO-Link master
