iGenix IG355X - INSTALLATION; Reversing the Door - Hinge and Feet Adjustment

9
2. Remove top cover and thermostat knob and place it
aside.
3. Unscrew top hinge and then remove door and place
it on a soft pad to avoid scratching.
4. Unscrew bottom hinge. Then remove the adjustable
feet from both side.
Unscrew
Screw
5. Unscrew and remove the bottom hinge pin, turn the bracket over and replace it.
6. Ret the bracket tting the bottom hinge pin. Replace
both adjustable feet.
