FD300 & 600 Operating manual
- GB 8 -
6,35mm (1/4") HALF BLIND DOVETAIL TEMPLATE
8mm (5/16”) & 12,7mm ( ½”) BOX JOINT TEMPLATES
12,7mm (1/2”) & 19mm (3/4“) THROUGH DOVETAIL TEMPLATE
32mm DOWELS JOINT
see inside each template packaging.
FD300 & 600 SPARE PARTS LIST v.5
Pos. # Description quantity code
Body FD300 1 FD3001-01
1
Body FD600 1 FD6001-01
Adjusting template comb stop FD300 2 FS100115
2
Adjusting template comb stop FD600 2 FS100116
3 Edge guide 4 FD3001-03
Clamp bar FD300 2 FD3001-95
4
Clamp bar FD600 2 FD6001-95
Template comb 12,7mm half blind dovetail FD300 1 FD3001-07
5
Template comb 12,7mm half blind dovetail FD600 1 FD6001-07
Clamp bar knob M8x90 FD300 4 FS200118
7
Clamp bar knob M8x90 FD600 6 FS200118
Washer 8 FD300 4 FS101004
8
Washer 8 FD600 6 FS101004
Spring FD300 4 FD6001-11
9
Spring FD600 6 FD6001-11
10 Screw M4 x 16 4 FS200126
Washer 6 FD300 2 FS101009
11
Washer 8 FD600 2 FS101001
Knob female M6 FD300 2 FS100106
12
Knob female M8 FD600 2 FS100108
Template brackets FD300 2 FD6001-22
13
Template brackets FD600 2 FD6001-21
14 Screw M4 x 8 4 FS200128
Screw M6 FD300 2 FS200138
15
Screw M8 FD600 2 FS200139
16 Rubber feet 4 FS990002
17 Sliding stop U-bracket FD600 2 FD6001-17
18 Screw M6 FD600 2 FS200112
19 Knob female M6 FD600 2 FS100106
