Quick GuideEN
Policies, standard documentation, ordering of spare parts and additional product information can be found by:
• Using QR code on your product.
• Visiting our website docs.whirlpool.eu and parts-selfservice.whirlpool.com
• Alternatively, contact our After-sales Service (See phone number in the warranty booklet). When contacting our After-
sales Service, please state the codes provided on your product‘s identication plate.
The model information can be retrieved using the QR-Code reported in the energy label. The label also includes the model
identier that can be used to consult the portal of the registry at https://eprel.ec.europa.eu.
IEC 436
:
TROUBLESHOOTING
Please scan the QR code on your product in order to have more detailed information.
PROBLEMS POSSIBLE CAUSES SOLUTIONS
The dishwasher
does not ll the wa-
ter. Display shows:
H , 6 and On/O
LED is blinking
rapidly
No water in the water supply or the tap is
closed.
Make sure there is water in the water supply or the tap running.
The inlet hose is bent.
Make sure the inlet hose is not bent (see INSTALLATION) reprogram the dishwasher
and reboot.
The sieve in the water inlet hose is clogged;
it is necessary to clean it
After having carried out the verication and cleaning, turn o and turn on the
dishwasher and restart a new program.
Dishwasher nishes
the cycle prema-
turely. Display
shows: 15 and On/
O LED is blinking
rapidly
Drain hose positioned too low or siphoning
into home sewage system.
Check if end of drain hose is placed at correct height (see INSTALLATION).Check for
siphoning into home sewage system, install air admittance valve if necessary.
Air in water supply. Check water supply for leaks or other issues letting air inside.
LOADING THE RACKS
CAPACITY: 14 standard place-settings
More information in the Daily Reference Guide on website.
CLEANING AND MAINTENANCE
CLEANING THE FILTER ASSEMBLY CLEANING THE SPRAY ARMS
A
A
B
C
In case you nd foreign objects (such as broken glass, porcelain, bones, fruit seeds etc.)
please remove them carefully.
NEVER REMOVE the wash-cycle pump protection (black detail) (Fig 4).
To remove the upper spray arm,
turn the plastic locking ring in a
clockwise direction.
The lower spray arm may
be removed by pulling it
upwards.
In case your dishwasher doesn’t work properly, check if the problem can be solved by going through the following list. For other errors or issues
please contact authorized After-sales Service which contact details can be found in the warranty booklet. Spare parts will be available for a period
of either up to 7 or up to 10 years, according to the specic Regulation requirements.
DELAY - The start time of the program may be delayed for a period of
time between 1 and 12 hours.
The DELAY function cannot be set once a wash cycle has been started.
TABLET (Tab)- If you use powder or liquid detergent, this option
should be o.
OPTIONS AND FUNCTIONS
OPTIONS can be selected directly by pressing the corresponding button (see CONTROL PANEL). If an option is not compatible with the selected program
(see PROGRAMS TABLE), the corresponding LED ashes rapidly 3 times and beeps will sound. The option will not be enabled.
MULTIZONE - If there are not many dishes to be washed, a half load-
ing may be used in order to save water, electricity and detergent.
Please scan the QR code on your product in order to have more detailed information.
AUTO DOOR is a convection drying system which automatically
opens the door during/after drying phase to ensure exceptional dry-
ing performance every day. Door opens at the temperature that is
safe to your kitchen furniture.
LOWER RACK
For pots, lids, plates, sa-
lad bowls, cutlery etc.
Large plates and lids
should ideally be pla-
ced at the sides to avo-
id interferences with
the spray arm.
The lower rack has tip-
-up supports which
can be used in a verti-
cal position when ar-
ranging plates or in a
horizontal position (lo-
wer) to load pans and
salad bowls easily.
(loading example for the
lower rack)
CUTLERY RACK
(loading example for the cutlery rack)
The third rack was designed to
house the cutlery.
UPPER RACK
(loading example for the upper rack)
Load delicate and light dishes: glas-
ses, cups, saucers, low salad bowls.
FOLDABLE
FLAPS WITH
ADJUSTABLE
POSITION
