COMPLIANT TIMING
*
Digital input is not compliant.
NOTE
Video Mode
Horizontal
Frequency
Vertical
Frequency
Dot Clock
VESA
VGA 640 × 480
31.469kHz 59.940Hz 25.175MHz
37.500kHz 75.000Hz 31.500MHz
37.861kHz 72.809Hz 31.500MHz
SVGA 800 × 600
35.156kHz 56.250Hz 36.000MHz
37.879kHz 60.317Hz 40.000MHz
46.875kHz 75.000Hz 49.500MHz
XGA 1024 × 768
48.363kHz 60.004Hz 65.000MHz
56.476kHz 70.069Hz 75.000MHz
60.023kHz 75.029Hz 78.750MHz
SXGA 1280 × 1024
63.981kHz 60.020Hz 108.000MHz
79.976kHz 75.025Hz 135.000MHz
PC9801 640 × 400 24.827kHz 56.424Hz 21.053MHz *
