Iiyama ProLite T2252MSC User Manual

ENGLISH
8 BEFORE YOU OPERATE THE MONITOR

Signal Timing
Change to the desired signal timing listed on page 24: COMPLIANT TIMING.
COMPUTER SETTING
ADJUSTING THE VIEWING ANGLE

TOUCH support operation system
Mouse Digitizer Gestures*
1
Windows8/8.1/10
Windows7
Windows

Vista
Windows XP
Mac OS/OS X
Linux
Android
Functions
Click
Drag
Double-Click
Mouse function
Right-Click
Flick
Visual feedback
Mouse & Digitizer functions
Press & Tap, Rotate, Zoom-in/out
The other OS Versions not listed are not supported.
: Supported : Not supported
*
1
Gestures can be supported by application programs.

For optimal viewing it is recommended to look at
the full face of the monitor.

Hold the stand so that the monitor does not
topple when you change the monitor’s angle.

You are able to adjust the monitor’s angle up to
73° upward, 3° downward.

In order to ensure a healthy and relaxed body
position when using the monitor at visual
display workstations, it is recommended that
the adjusted tilt angle should not exceed 10
degrees. Adjust the monitor’s angle to your own
preference.

Do not touch the LCD screen when you
change the height or the angle. It
may cause damage or break the LCD
screen.

Careful attention is required not to
catch your fingers or hands when you
change the height or the angle.
NOTE
3
73

Iiyama ProLite T2252MSC Specifications

General

Pixel pitch	0.248 x 0.248 mm
Aspect ratio	16:9
Screen shape	Flat
Display diagonal	21.5 \
Touch technology	Multi-touch
Separate H/V sync	Yes
Display brightness	250 cd/m²
Display technology	LED
Vertical scan range	55 - 76 Hz
Horizontal scan range	24 - 83 kHz
Touchscreen technology	Projected capacitive system
Contrast ratio (dynamic)	5000000:1
Display number of colors	16.78 million colors
Display diagonal (metric)	54.6 cm
Supported graphics resolutions	640 x 480 (VGA), 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1440 x 900 (WXGA+), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080)
Certification	CE, TÜV-Bauart, cULus, CU, EPEAT Silver
Product color	Black
Display viewable area (HxV)	268.11 x 476.64 mm
Dimensions (W x D x H) with stand	490.5 x 220.5 x 370.5 mm
Cables included	AC, Audio (3.5mm), HDMI, USB
Tilt angle range	-3 - 73 °
Number of OSD languages	10
Panel mounting interface	100 x 100 mm
On Screen Display (OSD) languages	CHI (SIMPL), CHI (TR), CZE, DEU, DUT, ENG, FRE, ITA, JPN, POL, RUS
AC input voltage	100-240 V
Power supply type	AC
AC input frequency	50 - 60 Hz
Energy efficiency scale	A to G
Power consumption (max)	26 W
Power consumption (typical)	18.1 W
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	5 - 35 °C
Storage relative humidity (H-H)	5 - 85 %
Operating relative humidity (H-H)	10 - 80 %
OmniTapps Multitouch compatibility	No
Windows operating systems supported	Windows 10 Education, Windows 10 Education x64, Windows 10 Enterprise, Windows 10 Enterprise x64, Windows 10 Home, Windows 10 Home x64, Windows 10 Pro, Windows 10 Pro x64, Windows 7 Enterprise, Windows 7 Enterprise x64, Windows 7 Home Basic, Windows 7 Home Basic x64, Windows 7 Home Premium, Windows 7 Home Premium x64, Windows 7 Professional, Windows 7 Professional x64, Windows 7 Starter, Windows 7 Starter x64, Windows 7 Ultimate, Windows 7 Ultimate x64, Windows 8, Windows 8 Enterprise, Windows 8 Enterprise x64, Windows 8 Pro, Windows 8 Pro x64, Windows 8 x64, Windows 8.1, Windows 8.1 Enterprise, Windows 8.1 Enterprise x64, Windows 8.1 Pro, Windows 8.1 Pro x64, Windows 8.1 x64, Windows Vista Business, Windows Vista Business x64, Windows Vista Enterprise, Windows Vista Enterprise x64, Windows Vista Home Basic, Windows Vista Home Basic x64, Windows Vista Home Premium, Windows Vista Home Premium x64, Windows Vista Ultimate, Windows Vista Ultimate x64
RMS rated power	4 W
Number of speakers	2
Harmonized System (HS) code	85285210

Weight and Dimensions

Depth (with stand)	220.5 mm
Width (with stand)	490.5 mm
Height (with stand)	370.5 mm
Weight (with stand)	4800 g
Depth (without stand)	48 mm
Height (without stand)	296 mm
