You have purchased an laboratory machine which meets the
highest engineering and quality standards.
In accordance with warranty conditions, the warranty period
is 24 months. For claims under the warranty please contact
your local dealer. You may also send the machine direct to our
works, enclosing the delivery invoice and giving reasons for the
claim. You will be liable for freight costs.
The warranty does not cover wearing parts, nor does it apply
to faults resulting from improper use or insufficient care and
maintenance contrary to the instructions in this operating
manual.
Plug-in power supply unit
Rated voltage VAC 100 - 240
Rated frequency Hz 50 - 60
Output voltage VDC 12
Absorbed power W max. 30
Output power W 7,2
Power input W 1,5
Drive
Speed adjustable
rpm
1000 .... 2800 ±25%
Operating time % 100
Protection class II
Pollution degree 2
Overvoltage category II
Protection class acc. to IP 40
DIN EN 60529
Ambient humidity (relative) % 80
Ambient temperature °C 5 to 40 (in operation)
Operation at the m max. 2000
terrestrial altitude above sea level
Transport temperature °C -25 to +70
Storage temperature °C -10 to +70
Weight kg 0,55
Installed weight (max.) kg 0,1
Test tube size mm ø 30
Dimensions (B x H x T) mm 95 x 70 x 110
Type of movement orbital
Orbital diameter mm 4,5
Touchfunction yes
Subject to technical changes!
Warranty Technical data
9
