iKarus C42 Series User Manual

Pilot Operating Handbook for the C42 Series
POH C42 SERIES ISSUE1 (B) REV7 25/04/2020 Page 15 of 73
1.6 Engine RPM Limitations
Maximum engine RPM: n = 5800 trs/min, for 5 min. max
Maximum continuous RPM: n = 5500 trs/min
1.7 RPM Gauge Markings
Yellow arc: n = 5500 - 5800 rpm
Red line: n = 5800 rpm
1.8 Flap Settings
Position I: cruising
Position II: take-off / landing
Position III: landing
1.9 Maximal Speed for Flap Settings
Position I: VNE (see 1.5)
Position II: max. 135 km/h (73 kts)
Position III: max. 120 km/h (65 kts)

iKarus C42 Series Specifications

General

Manufacturer	Comco Ikarus
Type	Light sport aircraft
Maximum takeoff weight	472.5 kg (1, 042 lb)
Engine	Rotax 912
Horsepower	80 hp (60 kW)
Cruise speed	160 km/h
Range	800 km
Service ceiling	4, 000 m
Stall speed	65 km/h
Rate of climb	5 m/s
