COMCO IKARUS
Maintenance Manual C42 Series
MaintenanceManual C42-
Series_Issue_VII_18.02.2014.doc
Revison No.:1 32 from 107
Electrical parts
Please refer to the schematics below.
Maintenance of the electrical system is in accordance with the Inspection schedule in
Section 1 – Inspections.
All defective electrical components must be replaced with new parts obtained only
from IFC / ISC ( COMCO IKARUS distributor )
Figure 33: Electrical parts (old regulator to 2008 )
Earthing points
Regulator / rectifier
Starter motor solenoid
