5
3
4
5
A
1
125 mm
878 mm
1466 mm
6
7
2
4
1.
found at the very beginning and trace a horizontal
level line across your wall where the cabinets will
be placed. This base line represents the height of
the cabinet legs.
2.
as before. This is where the top of your base
cabinets will end up.
3.
markings. This line represents the bottom position
of the wall cabinets and frames.
4. With the lines marked, double-check that your
plan.
5. Pay attention to the required minimum distance
between hob and hood. This can be found in the
extractor hood assembly instruction.
6. The dishwasher should only be installed between
two cabinets or at least between a cabinet and the
wall. This in order to secure the appliance properly
and provide support for the worktop.
7. If you have a kitchen with a corner, you build
the corner base solution with a regular 80 cm
positioning of this solution, see page XX.
Marking key measurements
There are some critical measurements you need to consider and mark on your walls in order to secure proper
the space needed for doors and drawers to open properly, making sure there are no collisions with for instance
radiators or window sills as drawers and doors are opened.
the reference point from which to measure when
marking the key measurements (see below).
Prepare your space by making sure your corners are
try square for the corners and a spirit level for the
If your corner and/or walls aren’t straight you may
need to use distances to make sure your kitchen
cabinets and frames become level and align properly.
For advice contact you local specialised dealer.
