ASSEMBLY
Before any work on the machine
(e. g., maintenance, tool change,
etc.) as well as during transport
and storage, set the rota tional
direction switch to the centre posi-
tion. Unintentional actuation of the On/Off
switch can lead to injuries.
Battery charging
Charging your hammer drill/driver
When the charger is connected to the
electricity supply, the red diode on the
hammer drill lights up. The diode lights up
while the battery is being charged (13).
Under normal conditions of use the
hammer drill can be recharged several
hundred times.
ATTENTION! The recharging process
generates heat in the battery.
Note: The battery that is supplied with
the hammer drill has been charged for test
purposes only and must be fully recharged
before use.
First read the safety instructions and then
follow the loading instructions. Insert the
charge connector into the socket (13)
in the hammer drill. Then connect the
charger’s transformer (16) to the electricity
supply.
Make sure that there are no knots or sharp
bends in the cable.
The charger’s transformer and the battery
have been designed to be used together.
NEVER use this charger to recharge
cordless tools or batteries from other
manufacturers. The battery will gradually
lose its charge over a period of time, even
if the tool is not used.
The lithium-ion battery is protected against
deep discharging by the “Electronic Cell
Protec tion (ECP)”. When the battery is
empty, the ma chine is switched off by
means of a protective circuit: The inserted
tool no longer rotates.
WARNING! Do not continue
to press the On/Off switch after the
machine has been automatically
switched off. The battery can be
damaged.
WARNING! Recharge the battery
on a non-ammable surface. Do not
recharge the battery for more than
eight hours. The red diode will turn green
when the battery has been fully loaded.
Disconnect the cable and store the
transformer in a suitable place when it is
not in use.
It is not advisable to recharge the battery
in temperatures below freezing.
When removing the battery from the
machine, actuate the On/Off switch
(6) until the battery is completely
discharged. Unscrew the screws in
the casing and take off the casing shell.
Disconnect the connections on the battery
and remove the battery (see gure B).
INSTRUCTIONS FOR USE
Changing the tool
The SDS plus tool holder allows for simple
and convenient changing of drilling tools
without the use of additional tools. Due to
their working principle, SDS plus drilling
9
