IKEA HW400 User Manual

ENGLISH 15
Removal of oven shelf carriers
Interior: the oven shelf carriers can be •
removed for easier cleaning. To do this,
remove all the shelves and spring off the
side carriers (Fig. 3).
Fig. 3
Removing the door
In case of removal of the door, make sure
the oven is off and cool. Then, follow these
instructions. The oven door is heavy.
To remove:
Open the door fully.1.
Positionthehooks“A”ofthehinges2.
outwards (see Fig. 1).
A
2x
Fig. 1
Close the door slowly until reaching 3.
thehooks“A”,makingsuretheylockin
theslots“B”ofthedoor,asshownin
gure2.
A
2x
B
Fig. 2
Using two hands, gently push the door 4.
inwards,allowingthedoorhinges“C”to
disengagetheslots“D”(seeFig.3),then
lift and pull the door outwards until it
comes off the oven (see Fig. 4).
C
D
2x
Fig. 3
Fig. 4

IKEA HW400 Specifications

General

Brand	IKEA
Model	HW400
Category	Hob
Language	English
