IKEA IBMS1455XB0 - Page 3

DOOR PARTS
3
For Model: IBMS1455XB0
(Black)
W10318642
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
Illus. Part
No. No. DESCRIPTION
1 Door Assembly
W10317088 Black
2 8205733 Hinge Assembly (2)
3
W10120236 Sliding Arm
4
W10128850 Sliding Arm Kit
5 8205683 Switch Holder (2)
6
W10217468 Switch (2)
7
W10217473 Push−Rod (2)
8 8205685 Spring Cam
9 8205704 Spring, Torsion
10 8205686 Support
11 4375346 Switch
