12
ENGLISH
Technical Data
This appliance has been designed,
manufactured and marketed in
compliance with the E.E.C. Directives.
The technical information is situated in
the rating plate on the internal side of
the appliance.
* Maximum speed (boost excluded).
Unit Value
Product Type Wall mounted hood
Dimensions
Width mm 898
Depth mm 471
Exhaust Height min/max mm 630/995
Recirculating Height min/max mm 715/995
Airow max* - Exhaust m3/h 400
Noise max* - Exhaust dBA 65
Airow max* - Recirculating m3/h 190
Noise max* - Recirculating dBA 70
Total Power W 116
Lamps info
Type LED BAR
Number & Power 2 x 3W
Socket N/A
Installation minimum height - gas hob mm 650
Installation minimum height - elec hob mm 500
Net Weight Kg 8,3
