No. Control Function
1 SCART To connect a
device with SCART
connection.
2 SCART adapter To connect a
device with
SCART connection
using the SCART
adapter.
3 HDMI 1 To connect
your most used
HDMI device, for
example your
set-top box if you
have one.
4 HDMI 2 To connect your
game console,
digital camera or
other HDMI device.
5
HDMI 3 (ARC) To connect an
HDMI device.
We recommend
you connect your
UPPLEVA or other
sound system here.
6 USB 1, 2 & 3 To connect a
USB device. For
example mouse or
keyboard for Smart
TV browsing, or
USB memory.
7 Common
interface
To insert your CI+/
CAM module.
No. Control Function
8 Antenna/Cable
input
To connect your
cable TV or antenna
cable.
9 Satellite input To connect your
satellite cable*.
10 To connect your
headphones.
11 LAN To connect your
network (ethernet)
cable.
12 Component
input (CMP)
To connect a
device with these
connections.
13 SPDIF out To connect your
home theater
system or sound
system.
14 CMP(YPbPr)
adapter
To connect a
device using the
Component video
adapter.
15 AUDIO in
adapter
To connect a
device using the
audio adapter.
16 TV control
buttons
Turn TV on and off.
*Satellite input is only available for some
models.
