Low Center of Gravity
The camera head is designed with a low center of gravity for operator comfort.
The camera head is compact, weighing less than 6 pounds.High-density CCDs are
used, and the power consumption is a low 15W, thanks to newly developed ASICs.
■
Shoulder Pad
A new non-slip material is used for the shoulder pad. Pad position can readily be
adjusted fore and aft, as well as right and left angle.
■
Filter
The HL-45A/45AW has a built-in CC filter
disk. A color temperature conversion filter
can be selected to best match surrounding
illumination conditions.
■
High-Resolution Viewfinder
The HL-45A/45AW comes standard with a
1.5-inch high-resolution viewfinder that
delivers a horizontal resolution of 600TV
lines. This ensures clarity and consistently
high image quality.
■
Menu Switch
Shutter speed and Super-V can be set with a
menu switch located on the switch panel.
Various camera settings can be made on
screen in a menu-driven manner, thereby
substantially improving ease of operation.
More Flexibility for High Image Quality
Design and Functionality
■
Variable Shutter
In addition to six shutter presets, a variable shutter is also employed which can be set
from 1/60.3 to 1/201(NTSC), 1/50.3~1/200(PAL) of a second.
■
+36dB Gain
A +36dB gain allows for minimum illumination of 0.7(HL-45A), 0.5(HL-45AW) lx
(f1.4). Because sensitivity is enhanced electronically, loss of resolution is minimized.
■
Memory Card
The HL-45A/45AW is memory-card-
ready so that camera operating status
can be stored. Thus, camera setup, color
matching and identical DTL settings for
several cameras is greatly simplified
( The SmartMedia with a capacity of
2MB is used for storage).
