3-3. Rating
(1) Input levels
· Composite input
VS : 1.0 Vp-p positiv e polarity
V: 0.7 Vp-p positive polarity (Japan, Europe)
V: 0.714
Vp-p positive polarity (U.S.A.)
· Sync input
4 V
- 6 V p-p negative polarity
· RGB input
VS : 1.0
Vp-p positiv e polarity
V: 0.7 Vp-p positive polarity
·
YPoPn input
When R, G, and
B all have sync
signals,
when only the G signal has a
sync signal, or when neither R, G, nor
B has a sync signal
The standard input is Beta or M
Il {SMPTE, NlO)
Beta <525/60 Hz>
Y signal White: 714 mVp-p
Setup: 53.6 mVp-p
Sync : 286 m Vp-p
Pn, PR signals: 700 mVp-p
(100/ 7.5/75/7 .5 COLOR BAR)
<625/50 Hz>
Y signal
White: 700 mVp-p
Setup : 0
mVp-p
Sync: 300 mVp-p
Po, Pn signals: 700 mVp-p
(100/ 0/75/0 COLOR BAR)
M
Il (SMPTE, NlO)
Y signal White: 700 mVp-p
Setup: 0
mVp-p
Sync: 300 mVp-p
Pn, Pn signals : 525 mVp-p
(100/ 0/ 75/0 COLOR BAR)
The monitor can be set from the front panel for
signals other tha n standa rd.
· Y/C input
Y signal : 1.0
Vp-p (VS)
C signal: 0.286 Vp-p (burst level)
· Digital input
ECL 10
K (8-bit or 10-bit)
(2)Input Impedance
Composite input, sync input, RGB input,
YPnPa
input
Y/C input
High-impedance bridge connection or
75!"1 terminator
(75!2 terminator plug is optional )
High-impedance bridge connection or
75!"1 terminator (switched)
Digital serial input
75il terminator only
Digital parallel input
110.I? terminator only
(3)Return Loss 46dB or high (10MHz)
3-4. Brightness and Contrast
(l) CRT: In-line electron gun dot shadow mask
(2)Horizontal Resolution:
Dot tri o pitch
TM20-30RH/RP : 0.28mm
TM20-20RH/RP : 0.43mm
TM14-20RH/RP : 0.31mm
When screen center is 35 Ft-L
TM20-30RH/RP : 900 lines or greater.
TM20-20RH/ RP : 700 lines or greater .
TM14-20RH/RP : 700 lines or greater.
(3)Preset Contrast :
Factory setting is 35Ft-L
(100% window signal input)
(4)Maximum Brightness:
TM20-30RH/RP : 50
Ft-L, or greater
TM20-20RH/RP : 50 Ft-L, or greater
TM14-20RH/RP : 70 Ft-L, or greater
(At 100% window signal input,
BRIGHTNESS PRESET,CONTRAST
MAX.)
3-5. Decoder Out (Option)
y: 0.7Vp-p
Pn, Pn: 0.525Vp-p
(100/ 0/75/0 COLOR BAR)
This applies at the time of signal input
for composite video, composite digital,
and analog componE·nts (for RGB and
YPnPn).
High-impedanc e output.
3-6. Luminance Signal and Video Signal Systems
(1) Frequency characteristic
60 to 10 MHz
+1, - 3 dB RGB input (NTSC)
50 to
10 MHz +1, -3 dB RGB input (PAL)
(2) Luminance Signal System
a)Fr equency responce:
±ldB at 50 to 7MHz (Notch OFF)
- 30dB at 3.58MHz (Notch ON)
b) 2T pulse and 2T Bar T pulse
(KPn) :
± 1% (Notch OFF)
± 2% (Notch ON)
c)Short-time Distortion
(Ksn):
± 1% (Notch OFF)
± 2% (Notch ON)
d)Sag: ·
± 1%
e)Linearity (DG):
Below
2%
- 5 -
