-4-
*Keep package materials away from
children as they may be dangerous for
them.
*Be sure that your child does not play with
the product. Do not allow kids to use your
product.
*If power supply cable is damaged, this
cable should be changed by its producer or
its service agency or a personnel who is a
specialist at the same level in order to
prevent a dangerous situation.
Warning about Transportation and Carriage
*All the materials used at package of your product are suitable for recycling.
*Please comply with the signs on the product's box during transportation.
*Hold the holders placed at sides of the box in order to carry your product.
If you need transportation;
*Keep the original box.
*Carry your product in its original box; comply with the carrying signs on the product's box.
If there is no original package;
*Do not put heavy material on the chimney hood.
*Keep the external surface from bash.
*Pack your product to avoid damages.
Installation, taking off your product from its package:
*Check if there is any deformation on your product.
*Transportation damages and failures should immediately be reported to the transportation
responsible.
*If you notice any damage please report to the seller.
*Do not allow children to play with packing material!!!
*In case of flame, cut power of the cooker
hood and the cooking appliances, cover the
flame. Never use water in order to
extinguish it.
Use “MAX 6 A” fuse at cooker hood
installment for your security.
“CAUTION: Accessible parts may become hot when used with cooking appliances”
''The appliance is not to be used by children or persons with reduced physical,
sensory or mental capabilities, or lack of experience and knowledge, unless they have
been given supervision or instruction''
-13-
FUSE
ELECTRONIC CIRCUIT
CAPASITOR
5 µ
f
/400 V
M
FUSE
800m³/h 5 Speed
FUSE
10
10
10
M
CAP
CAP
N
M
1
M2
M3
M4
M
5
LAMP
500 m³/h 3 Speed
FUSE
CONTROL PANEL
ELECTRONIC CIRCUIT
M
INPUT : 220 - 240 V AC / 50 Hz
WHITE
WHITE
LAMP
BLACK
BLUE
RED
WHITE
BROWN
YELLOW/GREEN
BLUE
800 m³/h 3 Speed
CONTROL PANEL
LAMP
WHITE
WHITE
BLACK
WHITE
BLUE
RED
BROWN
BROWN
YELLOW/GREEN
BLUE
INPUT : 220 - 240 V AC / 50 Hz
LAMP
BLACK
GREY
YELLOW
WHITE
BLUE
BROWN
RED
GREY
GREY
BROWN
YELLOW/GREEN
BLUE
WHITE
WHITE
WHITE
WHITE
ELECTRONIC CIRCUIT
BUTTON BOX
5µF
YELLOW-GREEN
(1)
(2)
(3)
YELLOW/GREEN
Eco 3 Speed
