Ikon ISP29 - Page 14

Service and Installation Manual
14
WIRING DIAGRAM
MODEL:IPP94
MODEL: ISP29/ ISP29M
THERMOSTAT DISPLAY
N
L
PLUG
OVERLOAD
PROTECTOR
ROOM
EVAP
SENSOR COMPRESSOR
CIRCUITALION
FAN MOTOR
M
M
CONDENSER
FAN MOTOR
CURRENT
RELAY
STARTING
CAPACITOR
THERMOSTAT DISPLAY
N
L
PLUG
OVERLOAD
PROTECTOR
ROOM
EVAP
CIRCUITALION
FAN MOTOR
SENSOR
CONDENSER
FAN MOTOR
COMPRESSOR
t ℃
PTC STARTER
DOOR FRAME HEATER
MIDDLE FRAME HEATER
DOOR
FRAME
HEATER
MIDDLE FRAME HEATER
