hipot.com 43
Resistance Display Range:
Resolution:
Accuracy:
1 - 1000 MΩ (4 Digit, Auto Ranging)
± (3% of reading + 2 counts) at test voltage > 500V
± (7% of reading + 2 counts) at test voltage ≤ 500V
HI and LO-Limit Range:
Resolution:
Accuracy:
0, 1 – 1000 MΩ
0 = OFF
Same as Resistance Display Accuracy
Ramp Timer Range:
Resolution:
Accuracy:
0.1sec or 2.0sec
0.1 sec
± (0.1% + 0.05 sec)
Delay Timer Range:
Resolution:
Accuracy:
0, 0.5 – 999.9 sec (0 = Continuous)
0.1 sec
± (0.1% + 0.05 sec)
GENERAL SPECIFICATIONS
Safety Agency Listing CE, cTUVus, RoHS2
PLC Remote Control Input:
Output:
Test, Reset, Interlock
Pass, Fail, Test-in-Process
Memory 5 memories
All memories are linkable
Security Run Only Mode (RUN) - To avoid unauthorized access to test parameters and memory
locations.
Memory Mode (MEM)- Allows access to memory locations but restricts any changes in
test parameters.
Current Meter Max Tester can be queried using optional USB connection and software commands for
maximum current measured during the test including Ramp Up and Dwell Time.
Line Cord Detachable 6 ft (1.8 m) power cable terminated in a three-prong grounding plug.
Terminations 6 ft (1.8 m) high voltage and return leads (2) with clips. An optional remote receptacle
box may be purchased for testing items terminated with a line cord. International
receptacles are also available.
Mechanical Tilt up front feet.
Dimensions: (WxHxD) 8.5 x 3.5 x 11.9 inches (215 x 88.1 x 300 mm)
16.93 x 5.20 x 11.84 inches (430 x 132 x 300 mm) - Model 298
Weight: 12 lbs (5.46 Kg)
46 lbs (25.4 Kg) - Model 298
Environmental Operating Temperature : 32° - 104°F (0° - 40°C)
Relative Humidity: 20 to 80%
Calibration Calibrated using standards with accuracies traceable to the National Institute of
Standards and Technology (NIST). Calibration controlled by software. Adjustments are
made through front panel keypad in a restricted access calibration mode. Calibration
information stored in non-volatile memory.
MΩ
0.001
0.01
0.1
100- 499 VDC
MΩ
1.000 – 1.999
2.00 - 19.99
20.0 – 1000
500 – 1000 VDC
MΩ
1.000 – 9.999
10.00 - 99.99
100.0 – 1000
