Orientation
Controls & Inputs
POWER
TUN
+
SOURCE
MIN MAX
DIMMER /
MEM+
PAIR /
ALARM /
MEM
–
CLOCK SET /
MEM
TUN
–
VOLUME
SPEAKER OUT
Dust Cover & CD Player
Display
Volume
Remote
Receiver
Power
Source
Clock Set/Mem
Alarm/Mem−
Dimmer/
Mem +
Pair/Stop
Play/Pause
Tune/Skip
Aux In (3.5mm audio input)
Connect Speakers
Be sure to match the positive (red) and negative (black) wires to their corresponding inputs.
