Fig. 13
Step 4
• Press the START key and keep it pressed, until displayed result is stabilized. Symbol
„“ indicates, that measurement is running.
If you need to lock the START key, proceed as follows:
• Press ▲ key and keep it pressed. Press the START key.
• Release both keys. Symbols „A“ and „“ are displayed, indicating that locking of the
START key is activated and measurement is running.
Step 5
• If locking of the START key is activated: measured value is automatically written to
the buffer after you cancel locking of the START key by means of ▲ key.
If locking of the START key is not activated: last measured value is displayed and
automatically written to the buffer after you release the START key.
• Switch off the main switch of equipment under test.
I diff. X
0.00 mA A
