FM Transmitter V11M11_IM_EN_11072008
www.i-Luv.com
- 9 -
SPECIFICATIONS
• Modulation: FM Stereo
• Tuning Type: PLL (Phase-Lock Loop)
• Frequency Range: 88.1MHz – 107.9MHz (Step: 0.1MHz)
• Frequency Response (Audio): 80Hz – 15kHz
• Audio Input Level: 800mV
• Total Harmonic Distortion: 2.0%
• Transmitting Power: ≤ 90 dBm
• Transmitting Range: ≤ 33ft (Limited by FCC)
• Power for iPod
o Operating Voltage: 2.7V – 3.5V
o Operating Current: 35mA (Max)
• Power Consumption: ≤ 100mW
• Operating Temperature: -4°F to 122°F (-20°C to 50°C)
• Storage Temperature: 14°F to 113°F (-10°C to 45°C)
• Unit Dimension (W x H x D)
o 67.35mmX226.5mmX52.7mm
o 2.65”X8.92”X2.07”
• Unit Weight: 122.5±3g
* Features and specifications are subject to change without prior
notification. The unit dimensions and weights are approximate.
