Iluv IMM9400 - Location of Controls

1
2
3
4
AUX IN PHONES
iLuv | 8iMM9400/9500 | V10M10_IM_EN_0605097 | iLuv
GETTING STARTED
Location of Controls (Top View of Main Unit)
GETTING STARTED
Location of Controls (Front View of Main Unit) - continued
26
24 22
21
2325
28
27
17
19
20
1. TIME SYNC/TIME SET
2. iPod / iPhone dock
3. PLAY / PAUSE ( )
4. FM MODE / STOP ( )
5. TIMER/MEMORY
6. UP ( )
7. SELECT
8. NEXT ( )
1
2
3 4 5
8910
11
12141516
76
13
9. DOWN ( )
10. PREV ( )
11. DIMMER
12. DISPLAY
13. CD SELECTION 1- 4
14. VOLUME + / -
15. AM/FM
16. MODE
17. iPod Dock Cover
18. POWER ( )
19. OPEN/CLOSE R
20. Right CD door
21. Remote control sensor
22. Headphone Jack
23. SD Slot
24. USB Port
25. AUX IN Jack
26. LCD screen
27. Left CD door
28. OPEN/CLOSE L
18
