iM3 Revolution 4DC- Mobile Installation Manual
iM3 Revolution 4DC- Mobile Installation Manual, version 4.5
Revision History
Date
Version
Author
Description
9/11/17
2.1
Alan Fennell
Add Warning Labels
9/19/17
2.2
Alan Fennell
Add Remote Sync Instructions
9/20/17
2.3
Jeremy Moran
Update Base instructions, wiring
for power connector, securing
remote to wall mount
9/22/17
3.0
Alan Fennell
Base and Scissor arm orientation
3/14/18
4.0
Alan Fennell
Update Contact Info. Add new
remote image. Update base
instructions. Add new image of
Revolution.
4/6/18
4.1
Alan Fennell
Update White 3pin Scissor Arm
Molex connector note. Pg 13, 14.
4/11/18
4.2
Alan Fennell
Update Attaching Generator
Head Instructions, P. 17
7/9/18
4.3
Alan Fennell
Update to Step 10. P. 20, Added
Step 11: Check for Arm Drift. P.
20. Added Step 12: Check tube
head rotation. P. 20. Added Step
13: Calibration Test. P.20. Added
Appendix 1-4. P. 24-29
7/12/18
4.4
Jeremy Moran
Update to Step 6: Added Main
Board layout description. Added
Step to include how to change
WiFi Channel. Added Appendix 5.
10/18/19
4.5
Alan Fennell
Updated
Title/Footer/Header/Index.
Update to Step 12. Added tube
head/scissor arm
functionality/performance test.
Updated Actuator adjustment
instructions. Updated Office
Hours.
