SPECIFICATIONS
SPECIFICATIONS
- 7 -
POWER @ 14.4V <1% THD + N
RMS AT 4 Ohm , STEREO
RMS AT 2 Ohm , STEREO
RMS AT 1 Ohm , STEREO 600W X 1CH 1200W X 1CH
S/N RATIO @ rated power
CHANNEL SEPAR ATION
INPUT SENSITIVITY
INPUT IMPEDENCE
SLEW RATE
DAMPING FACTOR @ 50 Hz
FUSE R ATIN G
* WIDTH
* HEIGHT
* LEN
G
T
H
DIMENSION
MODEL
SPEC.
250W X 1CH
400W X 1CH
> 98dB
0.05% / <1%
~~~~~~
0.15V ~6.0V
20 KOhm
25V / µSec
> 100 @ 2ohms
40A X 2
8.5” / 222mm
2.125” / 54mm
13.75” / 349mm
Q600.1
500W X 1CH
800W X 1CH
> 98 dB
0.05% / <1%
~~~~~~
0.15V ~6.0V
20 KOhm
30V / µSec
> 100 @ 2ohms
30A x 4
8.5” / 222mm
2.125” / 54mm
18.5” / 470mm
Q1200.1
RMS AT 4 Ohm , STEREO
RMS AT 2 Ohm , STEREO
RMS AT 4 Ohm , MONO 650W X 1CH 250W X 2CH
S/N RATIO @ rated power
THD+N typical/rated power
CHANNEL SEPAR ATION
INPUT SENSITIVITY
INPUT IMPEDENCE
SLEW RATE
DAMPING FACTOR @ 50 Hz
FUSE R ATING
* WIDTH
* HEIGHT
* LENGTH
DIMENSION
MODEL
SPEC.
175W X 2CH
325W X 2CH
> 100dB
0.05% / <1%
> 75dB
0.15V ~5.0mV
20 KOhm
25V / µSec
> 100 @ 2 ohms
30A x 3
8.5” / 222mm
2.125” / 54mm
17.25” / 438mm
Q700.2
75W X 4CH
125W X 4CH
> 100dB
0.05% / <1%
> 65dB
0.15V ~5.0mV
20 KOhm
23V / µSec
> 100 @ 2ohms
40A x 2
8.5” / 222mm
2.125” / 54mm
13.75” / 349mm
Q450.4
POWER @ 14.4V <1% THD + N
THD+N typical/rated power
