PWM MOSFET POWER SUPPLY AMPLIFIER
REMOTE LEVEL CONTROL
12dB/Oct. CROSSOVER
- VARIABLE HIGH PASS CROSSOVER (40Hz-250Hz)
- VARIABLE LOW PASS CROSSOVER (40Hz-250Hz)
VARIABLE 0dB TO 18dB BASS EQ AT 40Hz
PROTECTION CIRCUIT WITH STATUS LED
THROUGH OUTPUT RCA FOR RUNNING MULTIPLE AMPLIFIERS
SOFT START / MUTE CIRCUIT
2 OHM STEREO 4 OHM MONO OPERATION
- 1 -
INTRODUCTION
FEATURES - CLASS AB AMPLIFIER
Thank you for purchasing an Image Dynamics amplifier for your automotive sound system.
Your amplifier has been designed and manufactured to the highest standards ensuring
years of enjoyment in your vehicle. For maximum performance and extended warranty
coverage, we highly recommend that you have your new amplifier installed by an
authorized Image Dynamics dealer. Your authorized dealer has the training, expertise and
installation equipment to ensure optimum performance from this product. Should you
decide to install the ampli
f
ier
y
oursel
f
, please
t
ake the time to read this manual thorou
g
hl
y
decide to install the amplifier yourself, please take the time to read this manual thoroughly
s
o as to
f
amiliarize
y
oursel
f
with its installation requirements and setup procedures.so as to familiarize yourself with its installation requirements and setup procedures.
HIGH EFFICIENCY ALUMINUM HEAT SINK
HIGH CURRENT BI-POLAR OUTPUTS
