SYSTEM OPERATION
• OPERATOR ROLE:
• CHECK THE BELT TENSION (SEE SLIDE 65)
• LOAD CHIP TRAY ONTO INSPECTION PLATE
• SLIDE CHIP TRAY LID INTO FINGER SLOTS
• ADJUST INSPECTION PLATE TAB WITH THUMB SCREWS TO SECURE IN PLACE
• ENSURE THE TRAY IS PUSHED BACK ALL THE WAY AGAINST THE STOP
• SET THE WATER NOZZLE OFFSET VALUE (SEE SLIDE 66)
• ENSURE WATER IS TOGGLED ON/OFF ACCORDING TO YOUR PREFERENCE
• ENSURE THE NOZZLE IS PRIMED (MANUALLY DISPENSE WATER OUT OF THE NOZZLE TO CHECK)
• PLUG IN THE CAMERA USB TO THE EXTERNAL COMPUTER
• OPEN SPINVIEW AND CONNECT TO THE CAMERA
• START THE ROUTINE FROM THE START BUTTON OR OVER SERIAL CONNECTION
