IMC MISTRAL 13 Series Installation And Operating Manual

Mistral
M
60,
M
90
,
M
135
23
Mistral M
135
–
Series
13
Part No
Description
A11/279 Door Gasket
A11/286 Door Gasket (800)
A12/073 Pilaster Strip
A12/099 Shelf
A12/102 Wine Shelf
E76/267 Perforated Shelf LH 135
E76/268 Perforated Shelf RH 135
A12/036 Shelf Clip (6 per shelf)
A19/027 Glider Foot
A21/011 Lock, clip & keys
E76/221 Access panel
G30/561 Electronic Controller (Red)
E77/123 Drip Tray 135
G60/348 M5 Mains Cable
G60/349 Mains cable EU plug
S76/302 Refrigeration Pack
S76/308 Refrigeration Pack 220V-60Hz
J09/046 Condenser/fan motor assembly
G40/239 Condenser Fan – Motor Only
J09/042 Evaporator
J09/007 Service Drier
X08/057 (2mtr) Capillary V135
G96/049 Evaporator Fan
C46/001 Z Door Handle (State Colour)
S76/252 LED assembly (white)
S76/255 LED assembly (red)
S76/258 LED assembly (blue)
S76/261 LED assembly (green)
