IMC MISTRAL 13 Series Installation And Operating Manual

Mistral
M
60,
M
90
,
M
135
22
SPARE PARTS LIST
Mistral
M
60
–
Series
13
Mistral
M
90
–
Series
13
Part No
Description
Part No
Description
A11/278 Door Gasket A11/279 Door Gasket
A11/283 Door Gasket (850) A11/285 Door Gasket (850)
A11/284 Door Gasket (800) A11/286 Door Gasket (800)
A12/073 Pilaster Strip A12/073 Pilaster Strip
A12/091 Z1 Shelf A12/092 Z1 Shelf
A12/082 Wine Shelf A12/051 Wine Shelf
S76/025 Perforated Shelf 60 S76/024 Perforated Shelf 90
A12/036 Shelf Clip (4 per shelf) A12/036 Shelf Clip (6 per shelf)
A19/027 Glider Foot A19/027 Glider Foot
A21/011 Lock, clip & keys A21/011 Lock, clip & keys
E76/221 Access panel E76/221 Access panel
G30/561 Electronic Controller (Red) G30/561 Electronic Controller (Red)
G42/020 Plastic Drip Tray G42/020 Plastic Drip Tray
G60/348 M1 Mains Cable G60/348 M1 Mains Cable
G60/349 Mains cable EU plug G60/349 Mains cable EU plug
S76/300 Refrigeration Pack S76/301 Refrigeration Pack
S76/306 Refrigeration Pack 220V-60Hz S76/307 Refrigeration Pack 220V-60Hz
J09/054 Condenser/fan motor assembly J09/046 Condenser/fan motor assembly
G40/239 Condenser Fan – Motor Only
J09/026 Evaporator J09/045 Evaporator
J09/007 Service Drier J09/007 Service Drier
X08/057 (2mtr) Capillary 60 X08/057 (3mtr) Capillary 90
G96/049 Evaporator Fan G96/049 Evaporator Fan
C46/001 Z Door Handle (State Colour) C46/001 Z Door Handle (State Colour)
S76/250 LED assembly (white) S76/251 LED assembly (white)
S76/253 LED assembly (red) S76/254 LED assembly (red)
S76/256 LED assembly (blue) S76/257 LED assembly (blue)
S76/259 LED assembly (green) S76/260 LED assembly (green)
