IMD PTO15/2S - Technical Specifications; PTO Model Specifications

Page 17
7. Technical Specifications
PTO-Specifications
PTO 10/2 S PTO 15/2 S
Generator
Synchronous Synchronous
2-Pole 2-Pole
Alternator Speed
3600 rpm 3600 rpm
AC Output Max.
120V / 240V 120V / 240V
10.000 W 15.000 W
(83A / 42A) (125A / 62.5A)
Take Off Shaft Power
20 HP 29 HP
Shaft Speed
Standard 540 rpm Standard 540 rpm
Receptacles
b,h b,h,I
Dimensions (LxWxH)
29x35x38 35x35x38
Dry Weight
209 lbs 284 lbs
Receptacles:
I)125V/250V 175A
b) Duplex 125V 5-20 h) 50A 125V/250V L14-50
Options
Simultaneous 120V/240V Use
X X
Full Power 240V Outlet
X X
Voltmeter
X X
Magnetic Circuit Breaker
X X
PTO 3-Point Hitch for Traktor
O
PTO Base for Trailer or
Stand-By Mount O O
O=optional : X=standard
