Thanks to InP and dSP menus, it is possible to select the value of signal to
be measured as well as its corresponding display.
Programming is made on three different phases:
Input channel • Measuring range • Display
1 • Input channel
Select the channel within whose values the signal to be measured is included
Menu InP
Ch. input channel
2 • Measuring range
Program the correct beginning and end of measuring range values
(beginning and full scale)
Menu dSP
L.In beginning of measuring range value
H.In end of measuring range value
3 • Display
Program the values to be displayed corresponding with the measuring range
Menu dSP
dP. display decimal point
L.dS value to be displayed corresponding with the beginning
of the measuring range (L.In)
H.dS value to be displayed corresponding with the end of
the measuring range (H.In)
Exemple entrée – 150…0…150V correspondant à – 16,50…0…16,50kW
Ch. = Ch.1 (-200…0…200V)
L.In = -150,0
H.In = 150,0
dP. = 0,00
L.dS = -16,50
H.dS = 16,50
Exemple entrée 0…8,5V correspondant à 0…1250 tours/min
Ch. = Ch.2 (-20…0…20V)
L.In = 0,00
H.In = 8,50
dP. = 000
L.dS = 0000
H.dS = 1250
Exemple entrée – 60…0…60mV correspondant à – 1800…0…1800A
Ch. = Ch.3 (-200…0…200mV)
L.In = -60,0
H.In = 60,0
dP. = 000
L.dS = -1800
H.dS = 1800
Exemple entrée 4…20mA correspondant à – 100,0…100,0 kg
Ch. = Ch.4 (-20…0…20mA)
L.In = 4,00
H.In = 19,99
dP. = 00,0
L.dS = -100,0
H.dS = 100,0
