IMER U.S.A. Inc.
5
MINUTEMAN
The MINUTEMAN has a noise emission level of 68 decibels.
NOISE EMISSION LEVEL
WIRING DIAGRAM
WARNING
Any type of electrical repair or trouble-shooting should only be performed by an
IMER dealer or a properly qualified electrical repair shop.For assistance with
any electrical difficulty, IMER U.S.A. is always directly available for assistance.Call
415.872.2200 between 8-5 Pacific Standard Time.
PE
N
L1
S1
F2
C1
M1
AM
AA
Protection wire
Neutral wire
Phase wire
Stop and start button
Thermal protection for electric motor
Capacitor
Single phase motor
Motor winding
Motor winding
