Immersion RC Vortex - ESC, Receiver, and Flight; Weight and Size

ESC
Type
ImmersionRC EzESC
Rating
12A continuous, 17A peak
Features
OneShot125, and Motor Braking
Processor
32-bit ARM
R/C Receiver
Channels Required
Absolute minimum four. Five recommended to support mode switch.
Interface Standard
3.3v-5v PPM Sum (all channels in one PPM stream)
Receiver Power
+5v @ 200mA max. (3.3v supplied using the optional Spektrum Rx cable)
Flight Characteristics
Flight Time
Depends upon battery, and flight style
Maximum Range
Highly dependent on battery, and flying style
Maximum Speed
FAST (TODO: Anyone interested in testing and documenting?)
Camera Support
Onboard GoPro Supply
+5v at 1A
Video Standard
Composite, PAL or NTSC, switchable using a camera-mounted jumper
Weight and Size
Weight, as Shipped, ARF
~350g
Weight, Typical RTF
~528g w/1300mAh 45C 4s pack, and EzUHF 4 CH receiver
Size
283mm between diagonal motors, 210mm and 195mm front/rear
Folded Size
100(w)x300(L)x40(h)mm, without battery/GoPro/Mobius
