impro XTT901 - Antenna Reader Distance

XTT301-0-0-GB-20
March 2019
Page 3
XTT905
• An Impro KMA Antenna Reader housed in a Black, ABS Plastic housing. The
Impro KMA consists of a Front Cover and a Mounting Bracket (the Mounting
Bracket is attached with a Self-tapping Screw (M2 x 6 mm)).
• Four Counter-sunk Self-tapping Screws (M2 x 6 mm).
• An extra Serial Number Label.
XTT906 and XTT908
• Either an Impro RA Antenna Reader (XTT906-1-0-GB-XX) housed in PVC
sheathing. The Impro RA includes 8 m (26 ft) of 4-core cable.
• Or an Impro DPA Antenna Reader (XTT908-1-0-GB-XX) housed in a Black, ABS
Plastic housing. The Impro DPA includes 8 m (26 ft) of 4-core, 0.5 mm Solid
Strand Communications Cable.
• A Piezo-electric, External Drive Buzzer.
• A bi-colour Red or Green, White Diffused Lens, Hi-bright, 5 mm, 2-Terminal LED
(XTT906-1-0-GB-XX model only).
• An extra Serial Number Label.
XTT909
• Ten Impro CA Antenna Reader printed circuit board assemblies.
• An extra Serial Number Label.
XTT950, HLR905
• An Impro Antenna Junction Box Reader housed in a Black, ABS Plastic housing.
The Antenna Reader consists of a Front Cover and a Backing Plate Assembly (the
Front Cover is attached with a Combi Screw (6 mm x 2.2 mm)). The Backing Plate
Assembly includes 1 m (3.28 ft) of 10-core, 6.2 mm cable.
• An extra Serial Number Label.
General
Remember the following when installing the Antenna Reader:
Antenna Reader Distance
The ideal cable distance between the Terminal, Controller or Receiver and its Antenna
Reader ranges between 2 m to 16 m (7 ft to 53 ft).
NOTE: When used with the Impro iTT or the IXP20 Controller (iTT Platform) the
ideal cable distance between the Terminal or Controller and Non-keypad
Antenna Readers ranges between 2 m to 25 m (7 ft to 82 ft). The ideal
cable distance between the Terminal or Controller and Keypad Antenna
Readers ranges between 2 m to 16 m (7 ft to 53 ft).
Optimal performance is not guaranteed outside of the range. Achieve optimal
performance by using a good quality shielded multi-strand 3-pair twisted cable. The
cross-sectional area of the cable must not be less than 0.2 mm
2
(0.0003 in
2
).
