─ 8 ─

Exploded View and Parts List

Cross Bracket ASSY

ITEM NO.

Description QTY

1 Cross Bracket 1

2 Disk Cover 1

3 Washer Φ5.3*Φ10*1 4

4 Spring Washer Φ5 4

5 Pan Head Phillips Screw M5*20 4
