─ 11 ─
Console Panel Functions
CONSOLE PANEL FUNCTION
1. DISTANCE WINDOW
Indicates Kilometers or Miles traveled in 0.01 increments up to 9.99 and 0.1
increments starting at 10.0 (Range 0.01---999).
2. WATT WINDOW
Indicates user's current power ( Watt).
3. CALORIE WINDOW
Indicates estimated calories burned, based on user's weight, speed, resistance,
and time.
4. HEART RATE WINDOW
Indicates user's current heart rate (BPM).
5. TIME WINDOW
Indicates elapsed time after press Start in minutes and seconds (0-99minutes,
0-59seconds).
6. RESISTANCE WINDOW
Indicates workout in degree of Resistance L1—L20 in 1 increments.
7. SPEED WINDOW
Indicates workout laps per minute on pedal.
8. DOT MATRIX
8.1 Indicates ENTER WEIGHT KGS (or Lbs) when turn on power.
8.2 Indicates message when enter value.
8.3 Indicates workout curve in Program mode.
CONSOLE BUTTONS
1. START
This button is used to start the current program.
2. STOP
This button is used to stop the current program.
3. + and -
These buttons are used to adjust the degree of Resistance of the
machine during workout.
These buttons are also used to adjust the values when setting up your workout.
4. TARGET
This button is used to cycle through to the desired programs (time countdown,
calories countdown, distance countdown mode).
