40

Tread 3 times within 5 seconds on the end
part of the running belt. Heel keeps in touch
of running belt, and use sole to tread 3 times.
Strings will be lighted accordingly as in
below pics.
Eight strings two checks
Eight strings four checks
Eight strings six checks

1. Tread in constant speed area and speed
up area.
2. Tread not continuously, and fi nish 3
treads more than 5 seconds.

1. Using more than 100 mins continuously,
Mini Walk will stop automatically for
protection.
2. Power will be cut off automatically when
sleep mode lasts more than 10 mins.

1. Hydraulic handrail will lift automatically
when it is lifted to a certain height.
2. Hydraulic handrail will fold automatically
when it is folded to a certain height.
Max speed is 8km/h when handle is lifted.
Max speed is 6km/h when handle is folded.

1. Max ground clearance is 90 mm and min
is 47 mm. It can be put under a bed/
sofa or another other places which are
suitable for this size.
2. Wall suction storage. 2 magnets are
assembled in the end part of foot rails.
Place the round steel with sucker on the
suitable position on the wall. They will
attract together and insure the safety
when put Mini Walk against the wall.
