PAGE 09
SUITABLE PANS
Part
No
Description Qty Part
No
Description Qty
1 Warming Rack 1 13 Main burner 4
2 Stainless steel cooking
grid
1 14 Ignition cable 4
3 Cast iron flat plate 1 15 Control Knob 7
4 Flame diffuser 4 16 Igniter ( 1 for 5) 1
5 Screws (M5) 4 17 Knob bezel with blue LED 7
6 Light cover 2 18 Light /LED Switch 1
7 Screw 2 19 Grease tray 1
8 Light 2 20 Foot 4
9 Temperature gauge 1 21 Cable for light 1
10 Handle 1 22 Cable for LED 1
11 Hood 1 23 Transformer 1
12 Infrared rear burner 1 24 Built in supporting bracket-
L
1
25 Built in supporting bracket-
R
1
