PAGE 010
ASSEMBLY INSTRUCTIONS
WARNING
Ensure all transit protection is removed prior to
assembly.
1 Foot ( No.20)Assembly
2 Built in supporting bracket Assembly ( No.24.25)
3 Flame tamer ( No.4)assembly
4 Cooking grid( No.2)/plate ( No.3) assembly
5 Warming rack (No.1) assembly
6 Grease tray( No.19)
Installation Instructions
