Technical Specifications
Configuration SKU
Voltage 480Vac WYE, +/- 10 %
AC Input Power Connection 3-phase: L1, L2, L3, GND
Frequency 45-65 Hz
Recommended breaker 50A 3W+G circuit
SCCR 10 kAIC
Max Current Draw 39A
Power factor >0.99
THD - Current < 3%
Output Parameters Value
Voltage 150 - 1000Vdc
Current - Max 100A
Power - Max 30kW
System Efficiency - Max >94.5
Controls and Interface Value
Charging Connectors CCS1 & CHAdeMO
HMI 7” TFT LCD Display
Communication OCPP 1.6J
Network Connection LAN 10M/100M, Optional LTE wireless modem support
RFID Yes
Language English (others available on request)
Environment Value
Temperature - Operating - 4°F to + 158°F * / -20°C to +70°C (Optional: - 40°F / - 40°C)
Temperature - Storage - 40°F to + 167 °F / - 40 °C to +75 °C
Humidity 95%
Altitude - Operating 6560ft (2000 m)
Protection - Intrusion IP54/K10
General Value
Cable Length 16.4 ft (Optional: 25 ft)
Safety and EMI EN 61851-1-2001/EN 61851-21-2001/EN 61851-22-2001
* Derating characteristics apply at extreme temperatures
