Slim Square Dimensioner
Dimensions Slim/B
8.3 Slim Square
Type Volume gal. Weight lbs Heater element Heater element
option
Thermostat
mixer valve
601623Q000003 4.2 35 115V-750W 230V-750W X
Dimensions: See fi g 14
Material: Heat exchanger coil, storage tank and connections: stainless steel AISI 316
Outside cover and mouting brackets: Stainless steel AISI 304. Outer gables plastic.
Heater element: Nickel plated copper
Insulation: Polyurethane
Safety valve: 5.5 bar / 80 psi
Fig. 13
Fig. 14
000961
000963
