Isotemp Basic & Slim
Mounting alternatives, horizontal or vertical.
Fig. 2
001049
Isotemp Basic without and with thermostat mixer valve
ENGINE
MOTOR
WATER
ENGINE
MOTOR
WATER
FRESH COLD
WATER IN
Fresh warm water out
Engine water in or out
½" NPT outside thread
Fresh cold water in
FRESH WARM
WATER OUT
514
½"
½" NPT outside thread ½" NPT outside thread
ENGINE
MOTOR
WATER
ENGINE
MOTOR
WATER
FRESH COLD
WATER IN
-
+
WARM
OUT
Fresh warm water out
Engine water in or out
½" NPT outside thread
Fresh cold water in
½" BSP outside thread
514
½"
½" NPT outside thread
Fig. 3
